    N70 Maxx MY06-MY14

    $995.00

    Polaris 9″ android head unit to suit 2006-2014 N70 Toyota Hilux

    SKU: N70Maxx Categories: , ,

    Description

    Introducing the Enhanced N70Maxx: The Ultimate Upgrade for Your 2006-2014 Toyota Hilux. With a large 9″ touchscreen and integrated wireless Carplay and Android Auto, the N70Maxx offers a modern and seamless driving experience.

    Effortlessly integrate your favourite navigation apps like Newtracs, Wikicamps, Memory Maps, ExplorOz, Sygic, and more directly into your head unit. Customise your navigation experience to perfectly match your unique needs.

    Elevate your Toyota Hilux to new heights of personalisation and convenience with the N70Maxx. Experience the pinnacle of customisation and ease.

    • Wireless Carplay
    • Wireless Android Auto
    • Includes various air conditioning panels to accommodate different N70 dash layouts
    • AM/FM Radio
    • 9-inch
    • Wiring Harness included
    • Android 11
    • Bluetooth
    • Free Reverse Camera
    • Built-In Wifi
    • 4G Sim Compatible
    • Second Camera Input
    • High Definition Screen: 1280×800 with MiraVision
    • High-Quality Audio: MOSFET Amplifier
    • Download additional apps
    • Modern, User Friendly Interface

    Compatible vehicles:

    • 2006-2014 Toyota Hilux N70

    Parts Included for all N70 Models

    Includes various air conditioning panels to accommodate different N70 dash layouts

    Smartphone Integration

    Enjoy effortless smartphone connectivity with the N70Maxx. Thanks to its swift wireless connection, you can access your music, maps, and other approved* apps directly on the head unit from your phone. Eliminate the need to handle your mobile device while driving, ensuring a safer and more connected journey.

    *Note: While it doesn’t mirror your phone, it does display approved Apple and Google apps directly on the touchscreen with a dedicated driving-specific interface.

    Enjoy an Endless Supply of Navigation Apps

    Access navigation apps from your phone via Apple CarPlay or Android Auto, or download your favourite GPS apps directly to the N70Maxx head unit. With an external GPS antenna, you can download offline maps and navigate freely around Australia, ensuring you’re never lost even without a data connection.

    High Definition 9″ Screen

    The N70Maxx now features a significantly enhanced 9″ screen with a high resolution of 1280×800, offering crystal-clear visuals for your onboard head unit. Whether you’re using navigation, streaming music, or accessing apps, experience exceptional visual clarity and an elevated driving experience.

    Exceptional Sound Quality to Rival Leading Brands

    We know how crucial sound quality is to our customers, so we’ve enhanced our audio specifications to deliver clear, pristine sound. Add a subwoofer and amplifier, and you’ll elevate your car audio experience to new heights. Your car concerts have never sounded better.

    Multiple Camera Inputs

    The N70Maxx comes equipped with a high-definition mini camera featuring a butterfly bracket and a number plate camera for flexible mounting options. Additionally, you can connect a second camera for your caravan or trailer, providing enhanced visibility and safety.

    4G SIM Capability

    Simply insert a SIM card into the head unit to enjoy uninterrupted internet connectivity while on the move. Stay connected, stream music, use navigation apps, and experience a fully connected journey no matter where you travel.

    Intuitive Modern User Interface

    Discover our latest Android User Interface with a sleek, minimalist design that ensures ease of use for everyone. Enjoy a smooth and straightforward experience as you effortlessly navigate through features and settings.

    Wireless Software Updates

    Keep your head unit up-to-date effortlessly with wireless software updates. Enjoy a straightforward and efficient method to receive the latest features and enhancements without any hassle.

    Specifications



    System  Specifications
    CPU Cortex-A53  4CPU+4GPU, 2.0GHz
    RAM+ROM 6G+128G
    O/S Android 11
    PCB layer 8 layers with 2 ranks
    VIDEO RMVB,MKV,MOV,WMV,AVI,MPG, TS with 1080P H.264 format
    AUDIO MP3,WMA,WAV,OGG,FLAC,APE
    Steering Wheel control Supports (if applicable)
    Power off Shut off the OS, <10mA
    Working voltage DC12V
    Operating voltage range 10.8V ~16V
    Max current 10A
    Form Factor In-Dash
    Enclosure Type 1 DIN
    OSD Language English, Russian, Arabic, German, Spanish, French, Thai, Italian, Chinese + more than 63 languages
    Illumination control Yes
    Anti shock Mechanical anti-shock & Electronic anti-shock
    Features Bluetooth 5.0, FM AM Radio with RDS, GPS External Antenna, 2.4GHz and 5GHz WIFI, Rear Camera Input(AHD and CVBS compatible), Aux In, video out(CVBS out), USB multimedia playback, DSP, Front camera support, MiraVision (best display quality), 4.2 RCA with 2 way subwoofer control
    Display
    Touch Screen Multi-touch
    Display Mode 16:09
    Screen Size 9 inch
    Touch Screen Capacitive touch screen
    Screen Resolution 1280×800
    Display off Yes
    Carplay and Android Auto
    Wireless Supports
    Phone support Carplay for iPhone, Android Auto for Android phone
    Auto connect Automatic connection after pairing the first time.
    WIFI
    Dual band 2.4G and 5GHz
    Security WFA WPA/WPA2 Personal. AES-CCMP, WPI-SMS4, GCMP, WPS2.0, WAPI
    Frequency 2412MHz~2472MHz(802.11b/802.11g/802.11n(HT20))
    2422MHz~2462MHz(802.11n(HT40))
    GPS
    Map support Supports many different mapping applications
    Frequency GPS L1: 1559MHz~1610MHz
    Radio
    Radio IC SI47901
    Radio Tuner FM/AM RDS
    Support RDS Yes
    Frequency FM: 87.5~108 MHz, AM: 522~1620 KHz
    Amplifier
    Built-in Amplifier MOSFET
    Amplifier output power/channel qty. 50Wx4
    RCA Pre-outs 3 pair, 4V (Front/Rear/Subwoofer)
    EQ mode Flat, Powerful,Vocal, Natural, Insane, Unlimited Preset EQ Styles
    Customisable Graphic Equaliser  13-Band GEQ
    D/A Converter 24-Bit
    Crossover Network LPF/HPF
    Time Alignment  Yes
    Loudness Yes
    Subwoofer Control Yes
    LPF and HPF adjust Yes
    Bluetooth
    Version BT5.0 dual connection, support A2DP(Bluetooth Stereo Music)
    Built-in Microphone Yes
    External Microphone Yes
    Received Call Yes
    Dialled Call Yes
    Missed Call Yes
    Phone Book download Yes
    Frequency 2402~2480MHz
    Rear Camera Input
    Reversing mode The screen automatically displays rear camera video when reversing whether the power is off or on.
    Rear Camera Yes, included, AHD Miniature Camera with butterfly and number plate bracket included
    SD/USB
    Playback mode Automatic play multimedia when the device is connected unit
    SD map card slot Yes – located in the rear of head unit
    USB port 2
    Interface
    Video Input 3 Channel, One for front camera(CVBS/AHD)
    one for rear camera(CVBS/AHD),one for aux in(CVBS)
    Video Output 2 Channel(CVBS out)
    Audio Input 2 Channel for aux in
    Audio Output 4.2 Channel (FL/FR/RL/RR/SUB-L/SUB-R)
    USB Port Yes, 2 Rear USB port
    General
    Colour Black
    Operation Temperature -20℃~+70℃
    Storage Temperature -30℃~+80℃

    Additional information

    Weight 4.00 kg

    Frequently Asked Questions

    Please see below the different models that the N70 Maxx will fit:

    • 2006-2014 Toyota Hilux N70

    Includes various air conditioning panels to accommodate different N70 dash layouts

    No it does not move.

    Yes it is possible but you will require side brackets and a Toyota harness which are an extra $50.00:





    • N70 Hilux in dash unit
    • Wireless Carplay / Wired Android Auto Built in
    • Components for air conditioning panels that support both digital and dial controls.
    • Wiring Harness
    • GPS external Antenna
    • Bluetooth External Microphone
    • 2 x USB Cables
    • Cam in / Front Cam in plug
    • RR,RL,FR,FL Audio Out / Vid out 1& 2 / SUB
    • Vid In / AUX L / AUX R

    It is plug and play for the most part.

    The only hardwiring you will need to do is to pick up reverse power when installing the reverse camera.

    The only additional component we recommend is a Camera Retention Harness if you have a factory reverse camera and want to keep it.

    2014 Hilux: APVTY02 $20.00

    2012-2013: APVTY01 $20.00



    2 Years.

    The N70 Maxx now comes standard with Wireless Carplay & Wired Android Auto built in.

    There are also many different paid & unpaid mapping apps that you can download directly onto the head unit like:

    • Sygic Navigation
    • iGo Navigation
    • Tom Tom
    • ExploreOz traveller





    The beauty of owning an Android Head unit is you can add YOUR favourite navigation app via Google Play store.

    Options like:

    • HEMA 4×4 app
    • ExploreOz Traveller
    • Memory Maps
    • Gaia GPS
    • Newtracs
    • Australia Topo maps
    • Sygic Maps

    Alternatively, if you are looking for a custom off-road package, please visit www.gpsoz.com.au

    Yes, we have worked with the developers to ensure that their app works with our head unit.

    Exploreoz Traveller is a great mapping system for both on & off road with good reviews and might be worth checking out if you want a mapping system that provides the best of both worlds.

    Please note that there are a few settings that need to be changed which we can advise at the time of purchase.

    Apple CarPlay lets you use a selection of your Iphone’s functions directly through your car’s built-in infotainment system.  Apple CarPlay is often more user-friendly and faster to respond than the standard features built into many infotainment systems

    Android Auto brings a selection of apps to your car display so you can focus while you drive. You can control features like navigation, maps, calls, text messages, and music.

    Yes, your phone is still in use, but now it is displayed on the head unit with the CarPlay/Android Auto interface.

    No, The safety of drivers is a top priority for Apple CarPlay and Android Auto, which is why not all phone apps are available in CarPlay or Android Auto mode. Only apps approved by Apple will appear in CarPlay, and only apps approved by Google will appear in Android Auto.

    Yes you can pair your phone via bluetooth and:

    • Make / receive hand free phone calls
    • Import contacts
    • Stream audio via bluetooth

    Yes, you will still be able to use the bluetooth feature for calls and streaming audio and you will be able to use Apple Carplay on the head unit.

    No, but you can purchase a camera Retention Harness if you have a factory reverse camera and want to keep it.

    2014 Hilux: APVTY02 $20.00

    2012-2013: APVTY01 $20.00



    Yes, it will come with our AHD Mini Camera and also includes a number plate bracket for versatile fitting options.

    Yes the N70 Maxx has a second camera input which can be used for a front camera or a caravan camera.

    Yes, we have control boxes available that will allow you to add more cameras. Contact us at sales@polarisgps.com.au to get advice on the best setup for your application.

    Yes the unit comes with analogue AM/FM Radio

    Please note that it is not digital radio (DAB+), however you can download many different compatible radio apps on the head unit and stream radio*

    *Requires internet connectivity

    No

    No

    Yes the unit has 2 USB inputs.



    Yes, you can use a portable Wifi device or your phones personal hotspot to connect up to Wifi.

    Yes, it will work with a 4G Sim Card

    Yes, it is located at the back of the head unit

    Yes you can download compatible apps from Google Playstore or install android APK files.

    Please be aware that not all apps are compatible with the head unit. While we will assist you with third-party apps to the best of our ability, there may be some third-party apps that are not supported.

    You can see the specs at the bottom of the description

    Yes we have an OBDII Reader Add on ($50.00)

    Yes, we have an add on dash camera ($75.00)

    Yes, it is possible. However, installation of this unit requires specialised technical skills and expertise. If you are not confident in your ability to install the product or lack the necessary skills, please reach out to Polaris at 1300 555 514 or consult our list of dealers for assistance.

    Yes, please see our list of dealers:

        Yes, you can order online or give us a call on (02) 9638 1222 or 1300 555 514 to order the unit over the phone

        There are several reasons why we recommend our product over cheaper alternatives available online:

        1. We have over 40 years of business experience and more than 10 years of specialized head unit experience.
        2. In the event of any issues with the unit, you have immediate access to support through phone and online channels.
        3. Our after-sales support is unparalleled, frequently exceeding customer expectations.
        4. Our in-house team of two specialist technicians can repair all units, rather than sending them abroad for repairs.
        5. Some auto electricians may refuse to install low-cost, unknown alternatives.
        6. We offer superior optional extras and can assist with other extras not sold by us.
        7. We provide generous warranty periods and approach all warranty requests on a case-by-case basis.
        8. Our team of experienced staff has over 10 years of experience.
        9. We do not rely on drop shipping, ensuring direct control over the product.

        You can reach out to one of our experienced staff through the following ways:

        • Text us on 0483 930 453 or through the pop up on our website
        • Email us at sales@polarisgps.com.au
        • Give us a call on 1300 555 514 or (02) 9638 1222
        • Find us on facebook @mypolarisau and direct message us
        • Find us on instagram @polarisgps and direct message us
