• This is a universal style head unit with a Double din chassis and a 11" adjustable floating screen
• Will Suit vehicles with a double din space in their car
• Comes with a universal ISO harness, so will need to purchase correct harness for your vehicle or it can be hardwired in.

• Double DIN Head Unit with adjustable floating screen
• Wireless & wired Carplay
• Wireless & wired Android Auto
• Preloaded with Newtracs & Torque app
• Reverse Camera Included
• Cortex-A53 Processor
• Analogue AM/FM Radio
• Android OS
• Bluetooth
• 4 x AHD camera inputs
• WiFi
• 4G SIM compatible
• High Definition Screen 1280 x 800 QLED with MiraVision
• Over-the-air software updates
• Capacitive Touch screen
• RAM: 6GB
• Flash: 128GB
• High Quality MOSFET Amplifier
• 4 x 50 W/4 Ω Max.
• Modern, User Friendly Interface

• Head Unit double din base
• 11" Screen
• 1 x Reverse Camera of choice
• Wiring Harness (may have multiple to suit a wide variety of variants)
• GPS External Antenna
• Bluetooth External Microphone
• Fly lead with 2 x USB A inputs
• Fly Lead with 1 x USB A Input
• Fly lead with 4 AHD Camera Inputs
• Fly lead with CVBS Front Cam input & CAN power
• Fly lead with CVBS Rear Camera input, bluetooth & Wifi Antenna
• Fly lead with SIM Card input
• 2 x SIM External Antenna’s

System Specifications

• CPU: Cortex-A53 4CPU + 4GPU, 2.0GHz
• RAM + ROM: 6GB + 128GB
• Operating System: Android
• PCB Layer: 8 layers with 2 ranks
• Video Formats: RMVB, MKV, MOV, WMV, AVI, MPG, TS (1080P H.264)
• Audio Formats: MP3, WMA, WAV, OGG, FLAC, APE
• Steering Wheel Control: Supports (if applicable)
• Power Off: Shut off OS, <10mA
• Working Voltage: DC12V
• Operating Voltage Range: 10.8V ~ 16V
• Max Current: 10A
• Form Factor: In-Dash, No chassis
• OSD Languages: English, Russian, Arabic, German, Spanish, French, Thai, Italian, Chinese + 63+ languages
• Illumination Control: Yes
• Anti-shock: Mechanical & Electronic

Display

• Touch Screen: Multi-touch capacitive
• Display Mode: 16:9
• Screen Size: 11 inch
• Resolution: 1280 × 800
• Display Off Function: Yes

CarPlay & Android Auto

• Wireless Support: Yes
• Phone Support: CarPlay (iPhone), Android Auto (Android phones)
• Auto Connect: Automatic after first pairing

Wi-Fi

• Dual Band: 2.4GHz & 5GHz
• Security: WPA/WPA2, AES-CCMP, WPS2.0, WAPI
• Frequencies:
• 2412–2472 MHz (802.11b/g/n HT20)
• 2422–2462 MHz (802.11n HT40)

GPS

• Map Support: Multiple mapping apps
• Frequency: GPS L1: 1559–1610 MHz

Radio

• Radio IC: SI47901
• Tuner: FM/AM with RDS
• Frequency Range: FM 87.5–108 MHz, AM 522–1620 KHz

Amplifier (MOSFET, Class AB – STPA008)

• Output Power:
• 4 × 50 W into 4 Ω (max)
• 4 × 28 W/4 Ω @ 14.4 V, 1 kHz, 10% THD
• 4 × 72 W into 2 Ω (max)
• RCA Pre-outs: 3 pairs, 4V (Front/Rear/Subwoofer)
• EQ Modes: Flat, Powerful, Vocal, Natural, Insane, Unlimited presets
• Customisable Graphic EQ: 13-Band
• D/A Converter: 24-bit
• Crossover Network: LPF/HPF
• Time Alignment: Yes
• Loudness: Yes
• Subwoofer Control: Yes
• LPF & HPF Adjust: Yes
• Hi-Fi Class Distortion: THD as low as 0.01% @ 4W
  Channel Separation (Crosstalk): 75 dB @ 1 kHz, 60 dB @ 10 kHz
• Noise Floor: Output noise (A-weighted) as low as 40 μV
• Frequency Response: Extended up to ~100–300 kHz
• Voltage Gain: 26 dB fixed (±1 dB)

Bluetooth

• Version: BT 5.0 dual connection, A2DP (stereo music)
• Microphones: Built-in & external
• Call Support: Received, Dialled, Missed Calls
• Phonebook Download: Yes
• Frequency Range: 2402–2480 MHz

Rear Camera Input

• AHD: 4 x AHD Inputs (RCA)
• CVBS: 2 x CVBS Inputs (RCA)

SD/USB

• Playback Mode: Auto-play multimedia on connect
• SD Map Card Slot: Rear of unit
• USB Ports: 3 (rear)

Interface

• Video Output: 2 channels (CVBS out)
• Audio Input: 2 channels (Aux In)

General

• Colour: Charcoal
• Operating Temperature: -20℃ ~ +70℃
• Storage Temperature: -30℃ ~ +80℃
• Protections: Short-circuit, over-voltage/load dump (up to 50 V), thermal limit (smooth mute >150℃, shutdown >170℃), DC offset detection, clipping detection

Q: What is the difference between the Unimaxx and the Unimaxx+?

A: The Unimaxx+ brings a number of upgrades over the original. There's no CD/DVD player, but the specs are a big step up: 6GB RAM and 128GB storage, wireless CarPlay and Android Auto built directly into the head unit rather than run through a third party app, a better internal amplifier, a higher resolution screen, easier navigation, and over the air updates.

Q: Will this fit my car?

A: The floating screen design means the head unit can be adjusted up, down, left, or right to suit most dashboards. Aerpro install kits are available on our website, or we can order in specific parts for your vehicle.

Q: Does it support CarPlay and Android Auto?

A: Yes. Both wireless and wired CarPlay and Android Auto are supported and built directly into the hardware, so there's no third party app needed to run them.

Q: Does it come with a reverse camera?

A: Yes. A reverse camera is included and activates automatically when reverse is engaged.

Q: How many cameras can I connect?

A: The unit supports up to 4 AHD camera inputs.

Q: Can I play CDs and DVDs?

A: No.

Q: Does it retain steering wheel controls?

A: Because it's a universal unit, it's designed to fit a wide variety of vehicles. The unit comes with a standard ISO harness, so you can add an ISO vehicle wiring harness to make it plug and play. Alternatively, we also have complete wiring harnesses available for purchase for some models. If you don't see your model listed, reach out to us.

Q: Is installation difficult?

A: Installation is similar to most aftermarket head units. It comes with a universal ISO harness, external microphone, GPS antenna, and other miscellaneous fly leads that need to be plugged in. You'll need some general knowledge of car electronics.

Q: Can I customise the screen angle?

A: Yes. The 11 inch floating screen can tilt up and down, move side to side, and adjust vertically along its track for the best fit. The one thing to note with the up/down track movement is that it isn't as accessible to adjust while driving, since there are clips behind the screen that need to be released to move it along the track.
